Nutek – Stack Leadframe/ Magazine Loader – Semicon Series
This unit is used for loading of substrates, leadframes or carriers.
Technical Specifications
| Magazine | Specify upon order | |
| No. of Magazines | Depends on magazine type | |
|---|---|---|
| Loading Time | Average 8 seconds (excluding interleaf) | |
| Magazine Change-over Time | Average 20 seconds | |
| Indexing Pitch | 1 – 4 (5mm pitch) or specify | |
| Power Source | 100, 230VAC 1Ph | |
| Power Consumption | 1000VA max. | |
| Air Consumption | 15 tr/min. | |
| For further details, please refer to enclosed brochure. | ||
Available Models
| Model No. | Size | Machine Dimension (mm) L x W x H | Fixed Point to Front Dimension (X) | Weight (Approximately) | |
|---|---|---|---|---|---|
| NTM4413LM | M | 955 x 1120 x 1550 mm | 660 mm | 340 kg | |
| For further details, please refer to enclosed brochure. | |||||
Key Features
- Applicable to various substrates, leadframes or carriers
- Applicable to handle magazine of various sizes
- ‘Servo Control’ lifting/traversing motion
- High speed and precise indexing
- Easy loading or unloading of magazines
- Stores up to 10 different types of magazine dimensions
- Operation selectable between magazine or stack
- User friendly touch screen panel
- Fast product change-over cycle
- SMEMA compatible
Key Industries
- Semiconductor, Solar & Electronics
