A successful resistance spot welding process generally requires a welding power supply, a spot welding head, and a weld monitor or weld checker. Selecting the right accessories for these critical components can enhance and improve your results, and provide additional safety for your operators.

Combining a power supply, weld head, process monitor and workbench, the all-new WR Resistance Welding Workstations are designed to simplify welding tasks and maximize quality and reliability, while enhancing operator safety.

Key Features

• DC inverter technology with up to 60,000 A provided on the secondary
• “Cascade” feature to enable the use of one power supply with several workstations
• Integration with either an AMADA WELD TECH MH-1501 or KN-200A weld head
• Optional weld monitor
• Anti-tie-down buttons for safe operation
• Adjustable electrode speed

The Omega™ 4000 CO2 cleaning module provides powerful dry ice cleaning and surface preparation. The CO2 integrated spray is capable of quickly removing thin film, dust, and other surface contamination without damaging the part.

Uniquely designed, this compact cleaning unit comes in a stainless steel or powdercoated white frame. Test results have proven surfaces are prepared as good or better with the Omega™ 4000 than using etchants and dangerous solvents.

An optional, powerful combination of atmospheric plasma technology and integrated CO2 spray can be used to further break the bonds of tough organics. A final pass with CO2 spray removes the remaining debris, leaving a clean and high energy surface for bonding, coating, encapsulation, or under-fill processes.

The Omega™ 8000 CO₂ cleaning module is designed to operate 4 independent channels of CO₂ spray. By converting liquid CO₂ into solid CO₂ particles that are ejected out of the nozzle, it is possible to clean a wide variety of substrates. The CO₂ spray is combined with heated air propellant to form a non-condensing spray, leaving behind no residue after cleaning.

The Omega™ 8000 is configured with the SmartSpray™ process, which automatically adjusts the integrated spray, using pressure and temperature control, to maintain optimum user defined spray conditions. After being fully integrated, products don’t have to be removed, cleaned and returned to the production line, resulting in reduced human interaction, higher throughput and decreased cost-of-ownership.

OvenSENTINEL™, the latest continuous monitoring solution from ECD, sets the new standard in reflow process monitoring and product traceability. OvenSENTINEL leapfrogs competitor product to deliver unmatched measurement and visibility – down to the board and profile specification level – isolating and analyzing potentially damaging process variations. Completely customizable with user-specified dashboards, expanded sensor inputs, and flexible data extractions. OvenSENTINEL allows detailed and actionable reflow process oversight.

SmartDRY™ desiccant dry cabinet, for the storage of surface-mount technology (SMT) components with a Moisture Sensitive Level (MSL), intelligently maintains a low relative humidity (RH) as required by the IPC standard J-STD-033 while preventing electrostatic discharge (ESD) using durable electrically conductive powder paint surfaces over steel construction.

Fully network-capable with mobile connectivity and total accessibility from any networked device, ECD’s SmartDRY™ Intelligent Dry Storage technology enables compatibility with smart factory, Industry 4.0 operations.

Machine Quality Management (MQM) tools ensure soldering equipment – whether reflow, wave, or selective – is performing to specifications. Keeping a machine operating within its set tolerances sets a good foundation for product quality and high-yield operations. ECD MQM pallets use the M.O.L.E. thermal profiler as the data collection device, enabling the use of one data acquisition system that can be used across soldering equipment platforms.

Thermal profiling is the recording of time and temperature throughout a thermal process – most often to measure exposure within an oven. Used in many industries, thermal profiling collects data on a product’s thermal transformation experience, which is then analyzed to optimize complex process settings and conditions to ensure quality results.

A pioneer in the design of the traveling thermal profiler, ECD has developed a suite of thermal data logging products that serve the electronics, baking, industrial and solar industries, among others.

With a revolutionary new design, M.O.L.E.™ EV6 brings deep data collection and touch screen convenience to thermal profiling. The traveling thermal profiler allows configuration, measurement and data analysis right on the device – providing immediate actionable information, saving time and reducing the requirement for intensive operator training.

Using a familiar smartphone-like capacitive touch screen, users now have shop floor data literally at their fingertips. The six-channel M.O.L.E. EV6 integrates with all ECD RIDER™ machine quality management technologies for a truly scalable approach, made easier with visual, touch screen control.

Do you demand the highest density of thermocouple placement possible on your Hi-Reliability, High-Value PCB? ECD’s got your Spec! Do you expect a software package that flexes with your workflow, providing customizable data extractions, Imports of your .MDM M.O.L.E. libraries and compatibility with your intranet, Excel, and all ECD M.O.L.E.™ Profilers?

MEGAM.O.L.E.™ 20 delivers your specifications in a sleek 7.2mm thin package with patented productivity enhancing features that will give you the edge in R&D decision making to WOW. Management, Customers and your OEM-EMS QA linkage.

The V-M.O.L.E.™ is a full-featured compact thermal profiler that belies its sophistication in an easy-to-use 3-channel Mini-thermocouple configuration. Ideal for VERIFICATION of PCB profile performance, 3 channels give you Hot, Cold and Sensitive component data for verifying the correct oven settings.

The spectral output from an UV LED source is narrow or monochromatic when compared to broadband (mercury) source. Each of EIT 2.0 LLC’s L-Bands (L-365, L-385, L-395 and L-405) has an optic response and dynamic range optimized for LEDs. Our patented Total Measured Optic Response in which ALL optics in the instrument are included in the instrument response result in better performance and repeatability; unit-to-unit, run-to-run and source-to-source.

Online Monitoring allows users to continuously monitor and track a UV source. This is useful in applications where a radiometer will not fit, where high value and/or high production speeds are used and when it is not practical or easy to access each lamp (multi-lamp bank and/or elevated). The feedback is relative and looks at the relative output over time. Online Monitoring will identify both gradual (aging lamps) or sudden (equipment malfunction, user changed parameters) changes in the intensity.
