  • Freeze Dryers Brochure


Freeze drying, aka lyophilization or cryodesiccation, is a low temperature dehydration process which involves freezing the product, lowering pressure, then removing the ice by sublimation. With 3 models featuring temperatures from -110°C to -55°C and ice condensing capacity from 3 to 8 kg all goals of a lab can be virtually achieved.

Water may be a source of problems in many compounds and products that have to undergo tests and analysis and as a consequence it has to be removed and since time is a crucial issue it has to be done as quickly as possible. The undisputed advantages of freeze drying vs/ other techniques are the high quality of the final product due to the low temperature used during the process, the original shape of the product maintained and the quality of the d/rehydrated product that is simply excellent.

Technical Specifications

HyperCOOL HC3055HyperCOOL HC3110 HHyperCOOL HC8080
Ultimate Chamber Temp (at RT) (°C)-55-110-80
Chamber Volume (L) 4 254425
Trap (Chamber) Size (Ø x L)165 x 202165 x 202305 x 355
ICE Condensing Capacity (kg)338
Ice condensing performance (kg/day)2.52.53
Digital ReadoutTime, Temperature,Vacuum PressureTime, Temperature,Vacuum PressureTime, Temperature,Vacuum Pressure
FunctionKEYLOCK, DEFROST, VACUUM, TIMEKEYLOCK, DEFROST, VACUUM, TIMEDEFROST, VACUUM, TIME
Built in Vacuum PumpNoNoYes
Power supplyAC 230 V, 50 Hz (AC 220-230 V, 50/60 Hz; 110 V optional)AC 230 V, 50 Hz (AC 220-230 V, 50/60 Hz; 110 V optional)AC 230 V, 50 Hz (AC 220-230 V, 50/60 Hz; 110 V optional)
Power Requirement (KVA)2 KVA2.5 KVA5 KVA
Dimension (W x D x H, mm)5872195
Cat. No.Hyper-HC3055Hyper-HC3110Hyper-HC8080
CE MarkYesYesYes

Key Features

  • Provides wide solvent coverage by dropping temperature down to -55℃, -80℃, -110℃
  • HyperCOOL by itself, when equipped with manifolds or chambers, becomes a versatile freeze dryer
  • The compatible vacuum rotary vane pump generates vacuum down inside the chamber
  • Defrost Function available (Hot-gas)
  • Magnet embedded front cover of the condenser for very convenient cleaning
  • Extended applications for concentrating wider range or larger volume of solvents
  • Basic Model : 0~760 Torr (Vacuum value below “0” is not displayed)
  • Optional Pirani Sensor to display precise vacuum value below 1Torr (0.001~760 Torr)
