Kirsch Blood Bank Refrigerators
All KIRSCH Blood Bank Refrigerators offer you the best possible variant for the storage of your banked blood. All refrigerators are made of a robust housing, thick insulation, easy-to-maintain interior container, forced-air cooling, automatic defrosting, etc.
Available Models
Technical Specifications
| Capacity | 95 l |
|---|---|
| Temperature setting | +4 °C |
| Voltage | 220 – 240 V |
| Frequency | 50 / 60 Hz |
| Power consumtion | 160 Watts |
| Normal consumption | 0,85 KW / 24 h |
| Overall dimensions incl. distance from wall | 54 x 53,5 x 82 (w x d x h in cm) |
| Interior dimensions | 44 x 43 x 47 (w x d x h in cm) |
| Usable dimensions | 42 x 38 x 37 (w x d x h in cm) |
| Overall dimensions with door opened at 90° | 54 x 106 (w x d in cm) |
| Drawer inner dimensions | 37 x 32 x 10 (w x d x h in cm) |
| Loading capacity per drawer | 25 kg |
| Weight | 46 kg / 50 kg (net / gross) |
Overview
- 2·drawers
- Undercounter type
- Comfort controller
- Micro-processor controlled
temperature and thawing
regulation to maximize
temperature stability - Battery for power failure alarm
- Re-circulation air-cooling
- Automatic defrosting
- Melt water evaporation
- Easy accessible control panel with key switch
- Easy-to-read LED temperature display
- Optical and acoustical warning signal including power failure alarm
- Minimum/Maximum temperature memory
- Saftey control device prevents freezing
- Potential free contact and interface RS485
- Low-noise compressor
Technical Specifications
| Capacity | 170 l |
|---|---|
| Temperature setting | +4 °C |
| Voltage | 220 – 240 V |
| Frequency | 50 / 60 Hz |
| Power consumtion | 155 Watts |
| Normal consumtion | 1,4 KW / 24 h |
| Overall dimensions incl. distance from wall | 70 x 77 x 122 (w x d x h in cm) |
| Interior dimensions | 55 x 52 x 60 (w x d x h in cm) |
| Usable dimensions | 53 x 41 x 47 (w x d x h in cm) |
| Overall dimensions with door open at 90° | 70 x 136 (w x d in cm) |
| Drawer inner dimensions | 50 x 34 x 10 (w x d x h in cm) |
| Loading capacity per drawer | 50 kg |
| Weight | 79 kg / 89 kg (net / gross) |
Overview
- 2 aluminium drawers
- Comfort controller
- Micro-processor controlled
temperature and thawing
regulation to maximize
temperature stability - Battery for power failure alarm
- Re-circulation air-cooling
- Optimized ventilation plates to minimize interior temperature differences
- Automatic defrosting
- Melt water evaporation
- Easy-to-read LED temperature display
- Easy accessible control panel with key switch
- Optical and acoustical warning including power failure alarm
- Minimum/Maximum temperature memory
- Saftey control device prevents freezing
- Potential free contact and interface RS-485
Technical Specifications
| Capacity | 280 l |
|---|---|
| Temperature setting | +4 °C |
| Voltage | 220 – 240 V |
| Frequency | 50 / 60 Hz |
| Power consumtion | 155 Watts |
| Normal consumption | 1,5 KW / 24 h |
| Overall dimensions incl. distance from wall | 67 x 70 x 124 (w x d x h in cm) |
| Interior dimensions | 55 x 51 x 100 (w x d x h in cm) |
| Usable dimensions | 53 x 46 x 90 (w x d x h in cm) |
| Overall dimensions with door open at 90° | 67 x 128 (w x d in cm) |
| Drawer inner dimensions of 3 upper drawers | 49 x 39 x 10 (w x d x h in cm) |
| Drawer inner dimensions of the upper drawer below | 51 x 31 x 10 (w x d x h in cm) |
| Loading capacity per drawer | 50 kg |
| Weight | 82 kg / 92 kg (net / gross) |
Overview
- 4·aluminium drawers
- Comfort controller
- Micro-processor controlled
temperature and thawing
regulation to maximize
temperature stability - Battery for power failure alarm
- Re-circulation air-cooling
- Optimized ventilation plates to minimize interior temperature differences
- Automatic defrosting
- Melt water evaporation
- Drawers height-adjustable
- Easy-to-read LED temperature display
- Easy accessible control panel with key switch
- Minimum/Maximum temperature memory
- Optical and acoustical warning including power failure alarm
- Saftey control device prevents freezing
- Potential free contact and interface RS-485
Technical Specifications
| Capacity | 500 l |
|---|---|
| Temperature setting | +4 °C |
| Voltage | 220 – 240 V |
| Frequency | 50 / 60 Hz |
| Power consumtion | 316 Watts |
| Normal consumption | 2,5 KW / 24 h |
| Overall dimensions incl. distance from wall | 77 x 76 x 193 – 196 (w x d x h in cm) |
| Interior dimensions | 62 x 56 x 140 (w x d x h in cm) |
| Usable dimensions | 60 x 45 x 127 (w x d x h in cm) |
| Overall dimensions with door open at 90° | 77 x 144 (w x d in cm) |
| Drawer inner dimensions | 56 x 39 x 10 (w x d x h in cm) |
| Loading capacity per drawer | 50 kg |
| Weight | 124 kg / 154 kg (net / gros) |
Overview
- 5 aluminium drawers
- Comfort controller
- Micro-processor controlled
temperature and thawing
regulation to maximize
temperature stability - Battery for power failure alarm
- Re-circulation air-cooling
- Optimized ventilation plates to minimize interior temperature differences
- Rapid defrosting
- Melt water evaporation
- Drawers height-adjustable
- Easy-to-read LED temperature display
- Easy accessible control panel with key switch
- Minimum/Maximum temperature memory
- Optical and acoustical warning including power failure alarm
- Saftey control device prevents freezing
- Potential free contact and interface RS485
- Low-noise compressor
Technical Specifications
| Capacity | 700 l |
|---|---|
| Temperature setting | +4 °C |
| Voltage | 220 – 240 V |
| Frequency | 50 / 60 Hz |
| Power consumtion | 316 Watts |
| Normal consumption | 2,8 KW / 24 h |
| Overall dimensions incl. distance from wall | 77 x 98 x 193 – 196 (w x d x h in cm) |
| Interior dimensions | 62 x 77 x 140 (w x d x h in cm) |
| Usable dimensions | 60 x 66 x 127 (w x d x h in cm) |
| Overall dimensions with door open at 90° | 77 x 166 (w x d in cm) |
| Drawer inner dimensions | 56 x 60 x 10 (w x d x h in cm) |
| Loading capacity per drawer | 50 kg |
| Weight | 163 kg / 198 kg (net / gross) |
Overview
- 5 aluminium drawers
- Comfort controller
- Micro-processor controlled
temperature and thawing
regulation to maximize
temperature stability - Battery for power failure alarm
- Re-circulation air-cooling
- Optimized ventilation plates to minimize interior temperature differences
- Rapid defrosting
- Melt water evaporation
- Drawers height-adjustable
- Easy-to-read LED temperature display
- Easy accessible control panel with key switch
- Minimum/Maximum temperature memory
- Optical and acoustical warning including power failure alarm
- Saftey control device prevents freezing
- Potential free contact and interface RS-485
