Idex – Flow Regulating Valves – Selection Valves

Our Selection Valves are biocompatible & inert and deliver a low swept volume. Their unique design allows for minimal dispersion. Our selection valves come conveniently in both manual standard and bulkhead-mount versions. They have a pressure rating of up to 1,000 psi (69 bar). We offer two versions – one for 1/16 inches outer diameter tubing and another for 1/8 inches outer diameter tubing available in two configurations: standard manual and bulkhead-mountable manual. A valve mounting bracket is available to secure the bulkhead-mount versions to a lab bench or counter surface.

Inquiry Now

Overview

Features

Specifications

Available Models

Technical Specifications

Thread Port Configuration Coned1/4-28
MaterialPolymide/PTFE
Pressure Rating Max (psi)1000
Pressure Rating Max (bar)69
Positions6
Ports7
  • Selection Valve, 6 Position-7 Port, 0.040, For Tubing outer diameter 1/16 inches, Colour Black
  • Selection Valve, 6 Position-7 Port, 0.063, For Tubing outer diameter 1/8 inches, Colour Red

Our Selection Valve Assembly is ideal if your application involves low frequency of use and demands operator control or involves injection of smaller sample volumes. Both have 6 positions, 7 ports and 1/4-28 port configuration. The black 0.040 is for 1/16 inches outer diameter tubing and the red 0.063 is for 1/8 inches outer diameter tubing. Both include (6) XP-235 Fittings.

Technical Specifications

Thread Port Configuration Coned1/4-28
MaterialPolymide/PTFE
Pressure Rating Max (psi)1000
Pressure Rating Max (bar)69
Positions6
Ports7
  • Selection Valve Bulkhead, 6 Position-7 Port 0.040, For Tubing outer diameter 1/16 inches, Colour Black
  • Selection Valve Bulkhead, 6 Position-7 Port 0.063, For Tubing outer diameter 1/8 inches, Colour Red

Our Bulkhead Version Selection Valve Assembly is ideal if your application involves low frequency of use and demands operator control or involves injection of smaller sample volumes. Both have 6 positions, 7 ports and 1/4-28 port configuration. The black 0.040 is for 1/16 inches outer diameter tubing and the red 0.063 is for 1/8 inches outer diameter tubing. Both include (6) XP-235 Fittings.

Key Industries

  • Biopharmaceutical and Biotechnology
  • Chemical
  • Cosmetics & Personal Care
  • Education & Academics
  • Food & Beverage
  • Medical
  • Oil & Gas
  • Pharmaceutical
  • Powders & Pigments / Coating
